Compatible Power Supplies

이 리스트는 NVIDIA® GeForce® 9800 GX2의 원활한 사용이 가능함을 확인한 전원공급장치의 리스트입니다. 이 전원공급장치들은 전력 사용량을 충족시키고 있으며, 적어도 한 개의 6핀과 8핀의 PCI Express 전력 공급 케이블을 가지고 있으며,NVIDIA® HybridPower™ 모드를지원합니다.

주의 : 시장에서 구매할 수 있는 몇몇 시스템 전원공급장치는 모듈러 전원 공급 케이블을 가지고 있어 6핀과 8핀의 전력 공급 케이블이 같은 케이블에서 공급됩니다. 이런 전원공급장치들은 “8핀/6핀” PCI-E Express 전원공급장치로 분류되어 있습니다. 이런 모듈러 전원 공급 케이블은 기계적인 걸쇠를 가지고 있는데, 이는 너무 넓어 GeForce 9800 GX2 그래픽 카드의 PCI-E의 8핀 전원공급장치에는 맞지 않으며, 아래의 리스트에는 별표(*)로 표시되어 있습니다. 이 전력공급장치들은 GeForce 9800 GX2 GPU와 PCI Express 전원 공급 어댑터와 함께 동작 가능합니다. NVIDIA는 그래픽 카드 제조사와 전원공급장치의 제조사들과 함께 이 어댑터를 소비자들에게 제공할 것을 권유하고 있습니다. 구매한 제품의 제조사에 연락을 취해 연결 커넥터를 확보하십시오.

전원공급장치 모델

전력량

PCI Express 전원 커넥터 개수

단일 9800 GTX 지원

단일 9800 GX2 지원

2theMax RF Extreme 750

750W

Four 6-pin, Two 8-pin

Y

Y

AcBel Model PC6018

700W

Two 6-pin, Two 8-pin

Y



AcBel Model PC7030

750W

Two 6-pin, Two 8-pin

Y



Amacrox AX1000-GLN

1000W

Two 6-pin, Two 8-pin/6-pin*

Y



Amacrox AX750-EP

750W

Two 6-pin Two 8-pin/6-pin*

Y

Y

Amacrox AX850-EP

850W

Two 6-pin, Two 8-pin/6-pin*

Y

Y

Andyson AD-5600N2-18/AD-5620N2-yy

600W

One 6-pin, One 8-pin

Y



Antec Quattro TPQ-1000

1000W

Two 6-pin, Two 8-pin/6-pin *

Y

Y

Antec Quattro TPQ-850

850W

Two 6-pin, Two 8-pin/6-pin*

Y

Y

Antec SG-850

850W

Two 6-pin, Two 8-pin/6-pin*

Y



Antec SG-650

650W

One 6-pin, One 8-pin/6-pin *

Y

Y

ATNG APE-1100FM

950W

Four 6-pin, Two 8-pin

Y

Y

ATNG APE-1100XM

950W

Four 6-pin, Two 8-pin

Y

Y

ATNG Power APE-1100X(F) APFC PLUS

950W

Four 6-pin, Two 8-pin

Y

Y

BFG ES-800

800W

Two 6-pin, Two 8-pin/6-pin

Y

Y

Channel Well CWT-1000VC

1000W

Three 6-pin Three 8-pin

Y

Y

Channel Well CWT-1200VC

1200W

Three 6-pin Three 8-pin



Y

Channel Well CWT-750VH

750W

Two 6-pin Two 8-pin

Y

Y

Compucase (HEC ) HEC750DR-AT

750W

Two 8-pin, Two 8-pin

Y

Y

Cooler Master Real Power Pro (RS-C50-EMBA-D2)

1250W

Six 6-pin, Two 8-pin

Y

Y

Cooler Master Real Power Pro (RS-750-ACAA-A1)

750W

Two 6-pin Two 8-pin

Y

Y

Cooler Master Real Power Pro RS-A00-EFAM-A3

1000W

Four 6-pin, Two 8-pin

Y



Cooler Master Real Power M700 RS-700-ASAA-A1

700W

Two 6-pin Two 8-pin/6-pin*

Y

Y

Cooler Master Silent Pro M700 (RS-700-AMBA-D3)

700W

Two 8-pin*

Y

Y

Cooler Master Silent Pro M600 (RS-600-AMBA-D3)

600W

Two 8-pin*

Y

Y

Corsair HX1000W 1000W

1000W

Six 8-pin/6-pin *

Y

Y

Enermax EGX850EWL

850W

Two 6-pin, Two 8-pin*

Y

Y

Enlight ECP-750AAB A

750W

Four 6-pin

Y



FSP Group Epsilon 80 Plus

800W

Two 6-pin, Two 8-pin/6-pin

Y



FSP Group Epsilon 80 Plus

900W

Two 6-pin, Two 8-pin/6-pin

Y



FSP Epsilon 80Plus 700

700W

One 6-pin, One 8-pin/6-pin *

Y

Y

FSP Everest 800

800W

Two 6-pin Two 8-pin/6-pin*

Y

Y

FSP Everest 900

900W

Two 6-pin Two 8-pin/6-pin*

Y

Y

Gigabyte Odin (GE-MK20A-D1)

1200W

Three 6-pin, Three 8-pin

Y



Kingwin ABT-1000MA1S

1000W

Two 6-pin Two 8-pin/6-pin*

Y



Meridian XClio Diamondpower

880W

Two 6-pin Two 8-pin adapter Two 6-pin

Y

Y

Meridian XClio Diamondpower

1080W

Three 6-pin Three 8-pin adapter Two 6-pin



Y

Meridian XClio Diamondpower

680W

Two 6-pin Two 8-pin adapter Two 6-pin

Y

Y

Mtek Fonte Real Extreme 1200W

1200W

Three 6-pin, Three 8-pin *

Y

Y

Mtek Fonte Real Extreme 1000W

1000W

Three 6-pin, Three 8-pin *

Y

Y

OCZ EliteXStream

1000W

Four 8-pin/6-pin *

Y

Y

OCZ EliteXStream 800W

800W

Four 8-pin/6-pin *

Y

Y

PC Power and Cooling Silencer 500W EPS12V

500W

One 6-pin, Two 8-pin/6-pin *

Y

Y

PC Power and Cooling Silencer 500W (Dell)

500W

One 6-pin, Two 8-pin/6-pin *

Y

Y

PC Power and Cooling Turbo-Cool

1200W

Three 6-pin Two 8-pin adapter Three 6-pin

Y

Y

PC Power and Cooling Turbo-Cool

1000W

Two 6-pin, Two 8-pin/6-pin*

Y

Y

PC Power and Cooling Turbo-Cool 860

860W

Two 6-pin, Two 8-pin/6-pin*

Y

Y

Powerex REX-1000AS

1000W

Four 8-pin, Four 8-pin/6-pin*

Y



Powerex REX-850AS

750W

Four 6-pin

Y



Powerex XF - 850AMC

750W

Four 6-pin

Y



Powerex REX - 750AS

750W

Four 6-pin

Y



Powerex XF - 750AMC

750W

Four 6-pin

Y



Raidmax RX-1000

1000W

Four 6-pin

Y

Y

Raidmax RX-900

750W

Four 6-pin

Y

Y

Sigma SP-900

900W

Four 6-pin*

Y

Y

Sigma SP-1000

1000

Four 6-pin*

Y

Y

Silverstone Decathlon DA1200

1200W

Four 6-pin or Four 8-pin or Four 6-pin, Two 8-pin



Y

Silverstone Strider ST1000

1000W

Four 6-pin or Four 8-pin or Four 6-pin, Two 8-pin

Y

Y

Sirtec HPC-1000-G14C

1000W

Four 6-pin, Two 8-pin

Y



Sparkle SPI900GCM

900W

Two 6-pin Two 8-pin/6-pin*

Y

Y

Sparkle SPI1000GCM

1000W

Two 6-pin Two 8-pin/6-pin*

Y

Y

SPI Electronic Co., Ltd Epsilon 800

800W

Two 6-pin Two 8-pin/6-pin*

Y

Y

Super Flower SF-1000R14HE

1000W

Two 6-pin, Two 8-pin/6-pin

Y

Y

Super Flower SF-1100R14HE

1100W

Two 6-pin, Two 8-pin/6-pin*

Y

Y

Super Flower SF-850R14HE

850W

Two 6-pin, Two 8-pin/6-pin*

Y



Super Talent Atomic Juice PS-700

700W

One 6-pin, One 8-pin/6-pin*

Y

Y

TACENS Superpro 1000

1000W

Four 8-pin/6-pin*

Y

Y

TACENS Superpro 700

700W

Two 8-pin/6-pin*

Y

Y

Tagan BZ1300

1300W

Four 6-pin, Two 8-pin/6-pin

Y

Y

Tagan ITZ1300

1300W

Four 6-pin Two 8-pin/6-pin*

Y

Y

Tagan ITZ1100

1300W

Four 6-pin Two 8-pin/6-pin*

Y



Tagan BZ1100

1100W

Four 6-pin Two 8-pin/6-pin*

Y



Tagan BZ900

900W

Two 6-pin, two 6-pin/8-pin

Y



Tagan BZ800

800W

Two 6-pin, Two 8-pin/6-pin

Y

Y

Tagan ITZ800

800W

Two 6-pin Two 8-pin/6-pin*

Y

Y

Tagan TG1100-U96

1000W

Four 6-pin*

Y



Tagan TG-900-U96

900W

Four 6-pin

Y



Thermaltake Toughpower W0133 Cable Management

1200W

Three 8-pin Three 6-pin

Y

Y

Thermaltake Toughpower W0172 850 AP-1

850W

Two 6-pin, Two 8-pin

Y

Y

Thermaltake Toughpower (W0172)

850W

Two 6-pin, Two 8-pin

Y

Y

Topower EP-1200P10

1200W

Six 6-pin or Four 6-pin+Two 8-pin

Y

Y

Topower EP-1200P10-T2

1200W

Six 6-pin or Four 6-pin/8-pin +Two 8-pin

Y

Y

XIGMATEK NRP-HC1001

1000W

Three 6-pin, Three 8-pin*

Y

Y

XIGMATEK NRP-HC1201

1200W

Three 6-pin, Three 8-pin*

Y

Y

XIGMATEK NRP-HC1501

1500W

Four 6-pin, Four 8-pin*

Y

Y

Zalman ZM850-HP

850W

Two 6-pin Two 8-pin/6-pin *

Y

Y
